What do you call a hardtail race bike so light it can put most road bikes to shame? Well, we suppose you could call it a hardly-there-tail, but it actually goes by the name of the S-Works Epic Hardtail. Even while barely registering on the scale, we’ve loaded it with enough capability to do quite a number on the trail. Welcome to having your cake and eating it too—S-Works style.
- Ridiculously capable and refreshingly compliant with a weight that'll make most road frames jealous, the FACT 12m carbon S-Works Epic Hardtail frame isn't just light, it's the lightest production hardtail frame ever produced.
- Pairing 100 millimeters of the most efficient travel on earth with RockShox's svelte-yet-stiff SID SL Ultimate chassis, the RockShox SID SL Ultimate BRAIN fork serves as the pinnacle of XC-race suspension perfection.
- The pinnacle of drivetrain performance, SRAM's XX1 Eagle AXS combines next-gen wireless technology, incredibly accurate shift performance and game-changing versatility to drastically redefine the riding experience.
- Weighing a remarkable 1240 grams, the Roval Control SL wheelset not only increases strength and reduces weight, but also features a new 29-millimeter-wide internal width rim profile that improves pinch-flat resistance by 22-percent.
Small | Medium | Large | X-Large | |
---|---|---|---|---|
Crank Length | 170mm | 175mm | 175mm | 175mm |
Handlebar Width | 760mm | 760mm | 760mm | 760mm |
Stem Length | 60mm | 70mm | 70mm | 70mm |
Saddle Width | 155mm | 143mm | 143mm | 143mm |
Seatpost Length | 350mm | 400mm | 400mm | 400mm |
Stack | 608mm | 608mm | 622mm | 636mm |
Reach | 405mm | 430mm | 455mm | 480mm |
Head Tube Length | 95mm | 95mm | 110mm | 125mm |
Head Tube Angle | 68.5° | 68.5° | 68.5° | 68.5° |
BB Height | 309mm | 309mm | 309mm | 309mm |
BB Drop | 63mm | 63mm | 63mm | 63mm |
Trail | 101mm | 101mm | 101mm | 101mm |
Fork Length, Full | 506mm | 506mm | 506mm | 506mm |
Fork Rake/Offset | 44mm | 44mm | 44mm | 44mm |
Front Center | 670mm | 695mm | 725mm | 755mm |
Chainstay Length | 430mm | 430mm | 430mm | 430mm |
Wheelbase | 1092mm | 1117mm | 1148mm | 1178mm |
Top Tube Length, Horizontal | 579mm | 604mm | 633mm | 662mm |
Bike Standover Height | 762mm | 792mm | 816mm | 847mm |
Seat Tube Length | 400mm | 430mm | 470mm | 520mm |
Seat Tube Angle | 74° | 74° | 74° | 74° |
Inches | CM | SIZE |
---|---|---|
4'10" -5'1" | 148 - 155 | X-Small |
5'2" - 5'5" | 158 - 165 | Small |
5'5" - 5'10" | 165 - 178 | Medium |
5'10" - 6'1" | 178 - 185 | Large |
6'1" - 6'4" | 185 - 193 | X-Large |
6'3" - 6'6" | 191 - 200 | XX-Large |
Specs
Frame | S-Works FACT 12m, Progressive XC Geometry, Rider-First Engineered™, threaded BB, 12x148mm rear spacing, internal cable routing |
---|---|
Fork | RockShox SID SL ULTIMATE BRAIN, Top-Adjust Brain damper, Debon Air, 15x110mm, 44mm offset, 100mm Travel |
Rims | Roval Control SL, Carbon offset design, 29mm internal width, 4mm hook width, Tubeless ready, 24h |
Hubs |
Front: Roval Control SL, DT Swiss Internals, Ceramic Bearings, 6-bolt, 15mm thru-axle, 110mm spacing, Torque caps, 24h straight pull t-head Rear: Roval Control SL, DT Swiss 180 Internals, DT Swiss Ratchet EXP, Ceramic bearings, 12mm thru-axle, 148mm spacing, 24h straight-pull t-head |
Spokes | DT Swiss Aerolite |
Tires | Specialized Fast Trak, Control Casing, T5 Compound, 29x2.35 |
Bottom Bracket | SRAM DUB, BSA 73mm, Threaded |
Crankset | Quarq XX1 Powermeter, DUB, 170/175mm, 34t |
Shifters | SRAM Eagle AXS Rocker Paddle |
Rear Derailleur | SRAM XX1 Eagle AXS |
Cassette/Freewheel | Sram XG-1299, 12-Speed, 10-52t |
Chain | SRAM XX1 Eagle |
Brakes | SRAM Level Ultimate, 2-piston caliper, hydraulic disc |
Handlebars | S-Works Carbon XC Mini Rise, 6-degree upsweep, 8-degree backsweep, 10mm rise, 760mm, 31.8mm |
Tape/Grips | Specialized Trail Grips |
Stem | S-Works SL, alloy, titanium bolts, 6-degree |
Seatpost | S-Works FACT carbon, 10mm setback, 30.9mm |
Saddle | Body Geometry S-Works Power, carbon fiber rails, carbon fiber base |
Accessories & Extras | SWAT EMT Cage-Mount Tool |
* Subject to change without notice.
